Silicone Electric Cable Rubber Wire Flame-Retardant 18-30AWG
Description
Our ultra-flexible silicone rubber wire is engineered for superior performance in extreme environments. Ideal for industrial machinery, automotive applications, LED lighting, and high-temperature equipment, this wire combines exceptional flexibility with robust durability. The silicone rubber insulation ensures resistance to heat, chemicals, and abrasion, making it perfect for demanding electrical projects.
Key Features
Temperature Range: -60°C to +200°C (short-term 300°C)
Voltage Rating: Up to 600V
Flame Retardant: Complies with UL94 V-0 standards
Oil/Chemical Resistant: Withstands harsh industrial environments
Tangle-Free Design: Smooth bending for easy installation
Specifications & Models
| Model | AWG | Conductor Structure | Outer Diameter (mm) | Insulation Thickness (mm) | Current Rating |
|---|---|---|---|---|---|
| SF-SG18 | 18 AWG | 133/0.12mm (Stranded) | 3.5 ±0.1 | 1.0 | 15A |
| SF-SG20 | 20 AWG | 133/0.10mm | 3.0 ±0.1 | 0.8 | 10A |
| SF-SG22 | 22 AWG | 70/0.10mm | 2.5 ±0.1 | 0.6 | 7A |
| SF-SG24 | 24 AWG | 56/0.08mm | 2.0 ±0.1 | 0.5 | 3.5A |
| SF-SG28 | 28 AWG | 40/0.06mm | 1.5 ±0.1 | 0.4 | 1.4A |
| SF-SG30 | 30 AWG | 30/0.05mm | 1.2 ±0.1 | 0.3 | 0.8A |
Technical Advantages
Ultra-Flexible: Retains pliability even at -60°C.
Low Resistance: OFC conductor ensures minimal power loss.
Certified Safety: ROHS compliant, halogen-free.
Customizable: Cut-to-length services and custom labeling available.
——Our Feature——
1.Imported equipment with experienced technical team
We have three plant and has 3048 employees which have 206 engineers. Plant has a series of imported production lines including Niehoff copper drawing lines, Troster Germany and Maillefer Finland 500KV VCV lines, stranding machine from Pourtier France, SKET Germany, Caballe Spain, 220KV and 35KV production line plus SIKORA X – RAY 8000 on-line eccentricity measuring unit from Germany
2.Complete certification system
We have gotten ISO 9001, ISO 14001, OHSAS 18001. Plant passed TUV, VDE, UL, CE, SAA, BS etc. certificate.
3.Perfect Production system
Our products cover LV power cable, MV power cable, HV&EHV power cable, ABC cables, ACSR/AAC/AAAC/ACAR/OPGW ,submarine cable, control cable, instrumentation cable, building wire, flexible rubber cable, fire rated cable, renewable cable, solar cable, industrial cable, Lan cable, coaxial cable etc.
4.Perfect Sales service system
We can offer the OEM/ODM service, Multiple products, Skilled Export sale engineer team, Reasonable price, Reliable quality, Friendly service.
