Hslhch-Jz Halogen Free Flame Retardant Cables Screened Electronic Control Cables
Description
These cables are suitable for measuring, monitoring, and control cable for manufacturing of machinery, engineering and power stations, in heating or air conditioning and other electrical systems in dry damp interiors.
HSLHCH-OZ: Black cores with white numbering
HSLHCH-JZ: Black cores with white numbering ,Green/Yellow earthing core
HSLHCH-OB: Color code cores + without Green/Yellow earthing core
HSLHCH-JB: Color code cores + with Green/Yellow earthing core
Cable Construction
Inner Conductor : Electrolytic Twisted Copper Wire,Class 5 IEC 60228; DIN VDE 0295
Insulation : HFFR, EN 50334 black isulated cores with white number imprinted EN 50363-7
Stranding : Twisted in group
Inner sheath : HFFR, RAL 7001 Grey EN 50363-8
Screen : Tinned Copper Braid Wire
Outer sheath : HFFR, RAL 7001 Grey EN 50363-8
Technicial Properties
Operating Voltage : 300/500 V
Test Voltage : 2000 V
Insulation Resistance : 20 MΩ x km
Min. Bending radius : 10 x D
Operating Temperature : -30°C … + 70°C
Installation Temperature : 0°C … + 50°C
| Cable Description | No. Of Cores | Nom. Conductor Size | Nom. Cable Diameter | Nom. Cable Weight |
|---|---|---|---|---|
| mm² | mm | kg/km | ||
| 2 X0.5 | 2 | 0.5 | 4.6 | 28 |
| 3 X0.5 | 3 | 0.5 | 4.9 | 35 |
| 3 G0.5 | 3 | 0.5 | 4.9 | 35 |
| 4 X0.5 | 4 | 0.5 | 5.3 | 44 |
| 4 G0.5 | 4 | 0.5 | 5.3 | 44 |
| 5 X0.5 | 5 | 0.5 | 5.9 | 53 |
| 5 G0.5 | 5 | 0.5 | 5.9 | 53 |
| 7 X0.5 | 7 | 0.5 | 6.4 | 68 |
| 7 G0.5 | 7 | 0.5 | 6.4 | 68 |
| 9 X0.5 | 9 | 0.5 | 7.9 | 90 |
| 9 G0.5 | 9 | 0.5 | 7.9 | 90 |
| 10 X0.5 | 10 | 0.5 | 8.3 | 100 |
| 10 G0.5 | 10 | 0.5 | 8.3 | 100 |
| 12 X0.5 | 12 | 0.5 | 8.6 | 114 |
| 12 G0.5 | 12 | 0.5 | 8.6 | 114 |
| 14 X0.5 | 14 | 0.5 | 9.1 | 131 |
| 14 G0.5 | 14 | 0.5 | 9.1 | 131 |
| 16 X0.5 | 16 | 0.5 | 9.6 | 148 |
| 16 G0.5 | 16 | 0.5 | 9.6 | 148 |
| 18 X0.5 | 18 | 0.5 | 10.2 | 167 |
| 18 G0.5 | 18 | 0.5 | 10.2 | 167 |
| 20 X0.5 | 20 | 0.5 | 10.8 | 186 |
| 20 G0.5 | 20 | 0.5 | 10.8 | 186 |
