CAT6 Bulk Ethernet Cable
Description
Focus on OEM cable manufacturing more than 20+ years, committed to continuous production process and constantly meet customers’ cabling needs.Based on the needs of different OEM customers, we have developed four series of Networks cables.
1, E Series(Economic), Meet most cabling requirements, choose CCA conductor, working distance 100-120M for Networking Cabling. support 10-100Mbps, Good performance on CCTV Camera
2, B Series(Basic performance), Meet gigabit cabling standards,Choose Pure Copper Conductor, working distance more than 200M for Networking Cabling, support 10-100-1000Mbps, Better performance on CCTV Camera
3, HE Series( High quality Economic), Choose High quality CCA, and better HD-PE material import from America 3364, Korea 8380, Compared with B and E series, HE series has improved the material and production process, added two processes of untwisting and total Twisting, which Improved signal attenuation and Crosstalk, and improved performance
4, HP Series(Highest performance), Compare with HE series,Highest performance cable all choose Pure Copper, and Imported insulation , Jacket materials. This is for customers who have very high requirements for cabling, Fully satisfied Gigabit and 10-Gigabit cabling requirements.
| Model | E-UTP6 | B-UTP6 | HE-UTP6,HE-UTP6H | HP-UTP6 |
| Quality series | Economical | Basic | High quality Economical | High Quality Performance |
| Flu ke Pass | Not | Not | Yes | Yes |
| Shield Type | Unshield UTP | |||
| Conductor | CCA | Bare Copper | CCA,HCCA | Bare Copper |
| Copper Content | 25% | 100% | 30%,50%,60%,80% | 100% |
| Conductor size | 23AWG ( Customized) | |||
| Conductor resistance | 23Ω/100M | 7.0Ω/100M | CCA 16Ω/100M / HCCA 11Ω/100M | 7Ω/100M |
| Network working distance | ≤100M | ≥200M | ≤120M, ≤180M | ≥200M |
| IP camera working distance | ≤80M | ≤150M | ≤110M, ≤160M | ≥160M |
| OD | 6.1±0.02mm PVC/LSZH, CM,CMR ,CMP | |||
| Packing | 100M ,305M/Pull Box,500M/wooden drum | |||
| Color | White,Blue, Grey,Black,Orange,etc. Optional | |||
——Our Feature——
1.Imported equipment with experienced technical team
We have three plant and has 3048 employees which have 206 engineers. Plant has a series of imported production lines including Niehoff copper drawing lines, Troster Germany and Maillefer Finland 500KV VCV lines, stranding machine from Pourtier France, SKET Germany, Caballe Spain, 220KV and 35KV production line plus SIKORA X – RAY 8000 on-line eccentricity measuring unit from Germany
2.Complete certification system
We have gotten ISO 9001, ISO 14001, OHSAS 18001. Plant passed TUV, VDE, UL, CE, SAA, BS etc. certificate.
3.Perfect Production system
Our products cover LV power cable, MV power cable, HV&EHV power cable, ABC cables, ACSR/AAC/AAAC/ACAR/OPGW ,submarine cable, control cable, instrumentation cable, building wire, flexible rubber cable, fire rated cable, renewable cable, solar cable, industrial cable, Lan cable, coaxial cable etc.
4.Perfect Sales service system
We can offer the OEM/ODM service, Multiple products, Skilled Export sale engineer team, Reasonable price, Reliable quality, Friendly service.
